NPF-90 Series.png Features
Universal 90-305VAC input
Built-in active PFC function
High efficiency up to 91%
Short circuit, over current, over voltage and over temperature protections
Cooling by free air convection
Fully isolated plastic case
Fully encapsulated with IP67 level
Class II power, no FG
No load power consumption <0.15W
Part Number Voltage Current Power
NPF-90-12 12V 7.5A 90W
NPF-90-15 15V 6A 90W
NPF-90-20 20V 4.5A 90W
NPF-90-24 24V 3.75A 90W
NPF-90-30 30V 3A 90W
NPF-90-36 36V 2.5A 90W
NPF-90-42 42V 2.15A 90.3W
NPF-90-48 48V 1.88A 90.24W
NPF-90-54 54V 1.67A 90.18W


Specification

Voltage                                                   90 ~ 305VAC 127 ~ 431VDC
Frequency                                               47 ~ 63 Hz
Over Current                                          95 ~ 108% Protection type: Constant current limiting, recovers                                                                 automatically after fault condition is removed
Over Temperature                                  Shut down o/p voltage, re-power on to recover


Description

NPF-90 Series is a waterproof single output LED adapter with universal 90VAC to 305VAC input range and built-in PFC function. The units is enclosed within a 94V-0 flame retardant plastic case, which is fully potted with silicone, to enhance heat dissipation, meet 5G anti vibration demands and conform to IP67 level; making it ideal for highly dusty, humid or harsh environments. NPF-90 Series provide a high 91% efficiency and a low no load power consumption below 0.15W, meeting the energy saving demands of new generation LED lighting. Other features of this range of LED lighting power supplies include Class II design (no FG pin), free air convection cooling and Short circuit, over current, over voltage and over temperature protections.
